Eco Budget Package

Main Doors – Teak wood frame and shutter will be provided sizes are standard, door design will be standard, worth up to Rs.20000 including hardware.

Structural Analysis

Center line drawings

Excavation, sump & footing drawings

Column, plinth beam, footing, Roof slabs & beams drawings

shuttering drawings

Reinforcement drawings

staircase drawings

Texture paint willWater for construction, temporary power connection needs to provide client (our team will be support for approvals). be provided for front elevation.

Required approvals form the Govt. for construction of project (our team will be support to get approvals).

Road cutting, Mass excavation, Rock breaking, Rock drilling, expedience’s shall be borne by client

Electrical meter, Earthing, meter box and BESCOM charges shall be borne by client.

Elevation will be additional

To provide a space for material storage at site premises.

5 Years of warranty will be providing for structure and seepage problems.

Dedicated Civil Engineer, Supervisor team will be assigned for quality of work to be executed on site. Inspection of work progress and monitoring of required materials and labour force

Soil test will be done before going to structural design. soil SBC is considered as 180kn/m2.

Warranty from all the product will be availed directly from the manufacturer of the product.

Providing all the required bills to the client to clime the warranty.

Looking for Custom package and Material upgrades as per your requirement. Contact us for more information – 9975403841

Sanitary ware and CP fittings will be provided up to Rs.20,000 each toilet. (One number of Bathroom will be provided for each 700sq.ft of construction).

Bathroom tiles – branded wall tiles will be provided up to Rs.40 per sq. ft, antiskid floor tiles will be provided up to Rs.40 per sq.ft.

Tiles will be selected from Kajaria, Somany or any other brand as per client requirements.

cPVC and PVC conducts – Astral or equivalent brand will be provided

Frame and door – Sal wood frame and waterproof door shutter will be provided worth up to Rs.7500 including fixtures will be provided.

Slab electrical drawings

Proposed 2D floor plans

2D floor plans working drawings

2D schedule of opening drawings

2D plan Furniture layout

Basic 3D Elevation front view

3D elevation scheme details

3D elevation scheme details

Internal painting – Two coats of putty (Birla or JK brand make) for wall and ceiling, one coat of internal primer and Two coats of tractor emulsion paint will be provided.

External painting – One coat of exterior primer and two coat of Asian paints ACE weather proof paint will be provided.

Metal and Wood painting – Two coats of Asian paints enamel will be provided for window grills, M.S gate, M.S railings.

All paints shades will be selected as per client requirement, Asian paint brand make.

Parapet wall will be provided, standard height will be 3feet with block masonry.

Inverter provisions will be provided.

CCTV provisions will be provided.

Underground sump tank will be provided with 8inch thick block masonry, capacity of the tank will be 5000 liters (capacity will increase depends up on total buildup area)

Overhead tank with capacity of 1000 liter, ISI mark tribble layer tank will be provided

Anti-termite treatment will be provided

M.S main gate will be provided with standard design.

Standard Aluminium windows with 4mm clear glass with reinforced steel section frames will be provided

Window M.S safety grills will be provided with standard designs. Area of openings will be 7%.

Tiles will be selected from Kajaria, Somany or any other brand as per client requirements

Living and Dining – Branded vitrified tiles will be provided up to Rs.50 per sq.ft.

Kitchen and Rooms – Branded vitrified tiles will be provided up to Rs.50 per sq.ft.

Staircase flooring – Granite will be provided up to Rs.65 per sq.ft.

Granite selection as per client requirement

Balcony – Anti skid tile will be provided up to Rs.40 per sq.ft.

Parking – Parking tile will be provided up to Rs.40 per sq.ft

Wires – V-guard or Polycab or equivalent brand fire proof wires will be provided

Switches and panels – Ellyes orHI-FI entry modal equivalent brand switches and will be provided.

Toilets surfaces applying of acrylic polymer cementitious coating of brush bond will be provided, for covering of plumbing lines waterproof screed will be done.

Terrace waterproofing applying of acrylic polymer cementitious coating of brush bond will be provided and waterproof screed concrete will be done

External walls plastering with waterproof compound will be provided

Dr. Fixit or FOSROC brand waterproofing chemicals will be provided.

Kitchen counter top granite will be provided up to Rs.100 per sq. ft.

Kitchen dado tiles will be provided up to Rs.40 per sq. ft.

Kitchen sink will be provided up to Rs.2500

Sink Faucet and accessories will be provided up to Rs.1250.

Steel – India gold or RD TMT or equivalent brand, ISI mark Fe500 TMT steel will be provided, As per structural drawing reinforcement will be provided,(Rs.54/kg)

Cement – Dalmia or Birla or JSW or equivalent brand, 53, 43 grades cement will be provided.(Rs.350/bag)

Walls – Standard concrete solid blocks will be provided. for External wall 6inch thick, for Internal wall 4inch thick will be provided. (Wire-cut bricks can be used with additional cost Rs 120/ sq. ft on the package).

Walls – Standard concrete solid blocks will be provided. for External wall 6inch thick, for Internal wall 4inch thick will be provided. (Wire-cut bricks can be used with additional cost Rs 120/ sq. ft on the package).

Coarse aggregates – Standard 20mm, 40mm aggregates will be provided.

Fine aggregates – M-sand will be used for concrete and block masonry, plastering M-sand will be for plastering.

Concrete – As per structural Engineer recommendation will be provided

Ready mix concrete- Ready mix concrete will be provided for footings and roof slabs.

Floor height – Floor to floor height 10feet will be provided.
